This "build outside of OpenCPI" setup is missing an update in the
"develop" branch, causing two variables to be set incorrectly.

A short term workaround would be to set these variables properly after
including the ocpisetup.mk script in your Makefile:

OCPI_PREREQUISITES_LIBS:=lzma gmp gpsd ad9361
OCPI_API_LIBS:=application remote_support container library  msg
metadata transport xfer drc drc_ad9361 base util foreign os

I only tested this fix on centos7.

Hopefully this will get fixed in a future release.

Jim

On 5/11/23 5:50 AM, Ian Chodera wrote:

I have found that the ocpi_msg_driver_interface file is referenced from the $OCPI_CDK_DIR/include/setup-target-platform.mk file but doesn’t exist.
Changing msg_driver_interface to msg_drivers in that file fixes that specify linker error, but creates a whole lot of new errors!

On a related note: the SourceFiles attribute listed in "Table 8: Attributes in the Application Development XML File" on page 78 of the "OpenCPI Application Development Guide" doesn’t seem to do anything at all - the referenced file(s) don’t get compiled

Any help in adding other source files / libraries to my application would be appreciated

Thanks

Ian Chodera
MD1 Technology Ltd.

e: iac@md1tech.co.uk
w: www.md1tech.co.uk



MD1TechnologyLtd. is registered in England & Wales with company number 09378746.
Registered address: Cheltenham Film & Photographic Studios, Hatherley Lane, Cheltenham, Gloucestershire, England. GL51 6PN.
VAT registration number: GB 206 3877 05

I now have a custom makefile that lets the application compile

include $(OCPI_CDK_DIR)/include/ocpisetup.mk

HHApp: HHApp.cc
g++ -o $@ -std=c++0x $(OCPI_EXPORT_DYNAMIC) -I$(OCPI_INC_DIR) $<
-L$(OCPI_LIB_DIR) $(OCPI_API_LIBS:%=-locpi_%)
$(OCPI_PREREQUISITES_LIBS:%=$(OCPI_LIB_DIR)/lib%.a)
$(OCPI_SYSTEM_LIBS:%=-l%)
$(OCPI_ROOT_DIR)/exports/ubuntu22_04/lib/libocpi_base.a
$(OCPI_ROOT_DIR)/exports/ubuntu22_04/lib/libocpi_container.a
$(OCPI_ROOT_DIR)/exports/ubuntu22_04/lib/libocpi_drc.a
$(OCPI_ROOT_DIR)/exports/ubuntu22_04/lib/libocpi_drc_ad9361.a
$(OCPI_ROOT_DIR)/exports/ubuntu22_04/lib/libad9361.a

run: HHApp
OCPI_LIBRARY_PATH=$(OCPI_ROOT_DIR)/projects/core/artifacts ./$<

clean:
rm -f HHApp

I’m sure there is a better way to specify the libraries that are needed - what is it?
Why does a ‘empty’ OCPI application require AD6361 library to be linked - shouldn’t it be hardware agnostic?

BUT the main / biggest problem I am left with is that when I do an ocpidev run I get a missing worker error

app failed: No acceptable implementations found in any libraries for "local.HHProject.HHLib.HHComp".  Use log level 8 for more detail.

ocpidev show components shows that the component exists

| Library Package ID    | Component Pathname                                              | Component |
| --------------------- | ---------------------------------------------------------------- | --------- |
| local.HHProject.HHLib | /home/ian/maturation/ocpi/HHProject/components/HHLib/HHComp.comp | HHComp    |

And the app runs correctly if I delete the custom makefile. So what am I still missing from the makefile???

Ian Chodera
MD1 Technology Ltd.

e: iac@md1tech.co.uk
w: www.md1tech.co.uk



MD1TechnologyLtd. is registered in England & Wales with company number 09378746.
Registered address: Cheltenham Film & Photographic Studios, Hatherley Lane, Cheltenham, Gloucestershire, England. GL51 6PN.
VAT registration number: GB 206 3877 05

Hi Jim

Thanks for this info, I didn’t actually see your reply till after I found my crude compile fix. It is a neater way than I found, but essentially the same solution

The runtime problem still exists:

My app.xml instantiates a component
<Instance component='local.HHProject.HHLib.HHComp' externals='true' />

But at runtime the component isn’t found
app failed: No acceptable implementations found in any libraries for "local.HHProject.HHLib.HHComp".  Use log level 8 for more detail.

The component does exists (can be seen in the listing ‘ocpidev show components’ and if I build the application without the custom Makefile the app runs fine

Ian Chodera
MD1 Technology Ltd.

e: iac@md1tech.co.uk
w: www.md1tech.co.uk



MD1TechnologyLtd. is registered in England & Wales with company number 09378746.
Registered address: Cheltenham Film & Photographic Studios, Hatherley Lane, Cheltenham, Gloucestershire, England. GL51 6PN.
VAT registration number: GB 206 3877 05

This may be a consequence of (building and) running the app outside the
context of OpenCPI projects and ocpidev.
When applications are run, the binary worker implementations, in
"OpenCPI artifact" files, are found using OCPI_LIBRARY_PATH.
When ocpidev runs an application, it automatically includes any
projects' artifact directories in OCPI_LIBRARY_PATH, including any other
project dependencies.
In the "outside of OpenCPI projects and ocpidev" mode, you need to
manually set OCPI_LIBRARY_PATH to do that.
I.e., something like:
OCPI_LIBRARY_PATH=/home/me/opencpi-projects/HHprojects/artifacts:$(OCPI_ROOT_DIR)/projects/core/artifacts

I assume there is some good reason why you are avoiding ocpidev to build
and run the application.

Cheers,
Jim
